ROBOT CELL

The ultimate automation solution for your finishing process

Upgrade your finishing process and produce 24/7 with the Robot Cell. The most efficient solution for fully automatic loading and/or unloading of sheet metal parts in combination with a 1200 or 1500 mm wide Q-Fin finishing machine.

Download product flyer

Handling

Robots

Transportation

3D vision camera for product recognition
Undefined product picking
Gripper with vacuum or magnetic fixation
Connected input/output table for batch production
Recognition of length direction
ERP package integration via API
AGV integration possible with Qonnect+

Get your
competitive
edge

Robot Cell

Discover the Robot Cell by Q-Fin, the ultimate automation solution for efficiently placing undefined products on the input table of the Q-Fin finishing machine. Thanks to advanced 3D vision technology, the Robot Cell’s camera accurately scans and identifies the products, allowing the robot to effortlessly position them on the input table. This robot even offers the possibility of placing products in specific orientations, enabling you to achieve a perfect line finish in the desired direction.

Once the input table is full, the Robot Cell automatically communicates with the Q-Fin finishing machine, resulting in the products being processed by the Q-Fin finishing machine. This leads to seamless batch production of the products. Furthermore, it provides the flexibility to install the Robot Cell on the output side of the Q-Fin finishing machine, allowing for fully automated unloading of undefined products. Discover the efficiency and precision of the Robot Cell and optimize your production process.

Watch video

Technical Specifications

	Robot Cell 2M	Robot Cell 3M	Cartesian Cell
Avalable as	RC1200	RC1200, RC1500	CC1200, CC1500
Maximum workpiece weight	12 kg	70 kg	50 kg
Productfixation	Vacuum or magnet system	Vacuum or magnet system	Vacuum or magnet system
Minimum product thickness	1 mm	1 mm	1 mm
Maximum product thickness	10 mm	25 mm	25 mm
Minimum product dimensions	120 x 120 mm	120 x 120 mm	120 x 120 mm
Maximum product dimensions	300 x 400 mm	1200 x 800 mm	1200 x 800 mm
Machine power supply	400 V \| 50 Hz \| 10 A	400 V \| 50 Hz \| 16 A	400 V \| 50 Hz \| 32 A
Pallet size	1200 x 800 mm	1200 x 800 mm	1200 x 800 mm
Surface dimensions (L x W)	2000 x 1200 mm	3000 x 1200/1500 mm	3000 x 1200/1500 mm
Dimensions (L x W x H)	3000 x 3500 x 2200 mm	5000 x 5000 x 2200 mm	4700 x 4400 x 4300 mm
Suitable for	F1200, M1200 and SER1200	F1200, F1500, M1200, M1500, SER1200 and SER1500	F1200, F1500, M1200, M1500, SER1200 and SER1500
