SER1200 XL Multibrush

Quality Finishing, even better.

For deburring, edge rounding with R2, non-directional and line finishing of sheet metal parts up to 1200 mm wide.

SER1200 XL Multibrush

With the SER1200 Multibrush from Q-Fin, you can perform multiple operations in one pass on sheet metal parts up to 1200 mm wide. Deburring, edge rounding, Radius 2, oxide layer removal, line finish or non-directional finish. It is all programmable for the automatically adjustable operating stations.

• Fastest and most complete deburring and finishing machine
• Suitable for non-directional finish, line finish and Radius 2
• Easy-to-use HMI screen with adjustable programs
• Reproducible finish quality with error elimination
• Combination of operations programmable

Suitable for

Dowling Metal Products chooses Q-Fin

‘’Finishing is going really well. Much faster than I expected, the customers are very happy and the bar has gone up. I am really glad with the outcome of the machine. Now I’m learning more about linishing and edge rounding. I feel our decision for the Q-Fin machines will give us the lead on other customers. We will test the machines to the limit.”

– Michael Dowling
Director at Dowling Metal Products

Specs

- Conveyor belt speed adjustable: 0.3 - 8 m1/min
- With vacuum or magnet support
- 2 pcs. 7.5 kW grinding unit with frequency controlled
- 4 pcs. 2.2 kW brush motors with frequency control
- 7.5 kW Multibrush motor with frequency control
- Min. workpiece dimensions: 80x80 mm
- Maximum workpiece width: 1200 mm
- Maximum workpiece height: 150 mm
- Machine power supply: 400 V, 50 Hz, 63 A, 32 kW
- Dimensions: 4105 x 2205 x 2320 mm (L x W x H)

6.000 KG
Download brochure Download technical specs

Recommended combinations

CB 400 / CB800 button
Return conveyor belt
IOC / IC button
Infeed/outfeed conveyor belt
WES6000 button
Exhaust system with wet filter
